Laboratory Container Mixer Lab CM

Laboratory container mixer for intensive powder mixing, paints, and masterbatch. Short mixing times, scale-up, and easy cleaning.

• Various tool and motor combinations
• Flexible mixing in 6 or 12 liter containers
• Laboratory mixer for all common mixing processes
• Ideal for product development, research, quality assurance and small-scale production in all industries
• Scale-up from laboratory to production possible
• Mixing of small batches
• Extremely short mixing time from 3 minutes
• No product contamination due to the closed mixing chamber
• Realistic simulation of production results
• Individual configuration of mixing tools
• Variant as laboratory heating mixer available
• Convenient exchange of mixing vessels and mixing tools
• Can be used for a wide variety of mixing tasks with many tool and motor combinations
• Laboratory mixer is not a tabletop unit, yet space-saving and easy to install via Plug & Play
• Low energy consumption
• Easy and quick cleaning
• Intuitive operation in manual or automatic mode
• Additional functions such as dust removal, injection, and remote maintenance
• Innovative, web-based control with real-time visualization many mixing tasks
• Homogenize
• Dispersing
• Agglomeration
• Deagglomeration
• Comminution
• Digestion
• Fiber pulping and dyeing
• Absorbing
• Homogenization of bulk materials
• Improvement in product quality
• and much more
• proven mixing technology
• additional heating of the mixed material
• optimal homogenization
• suitable for many mixing materials
• Powder coating premixes, granules with granules, powder with powder, granules with powder
• 5-10 m/s
• Mixing of temperature-sensitive materials, e.g. PTFE premixes
• Mixing tool: 5-10 m/s, copper: ca. 40 m/s
• Color concentrates, masterbatch
• 25-40 m/s

The MIXACO laboratory container mixer Lab CM is suitable for mixing small quantities. In addition to product development, these are also required for production monitoring.

Despite its compact size, it has all the advantages of a large container mixer. Especially when used in laboratories, the container with volumes of 6 or 12 liters is very easy to transport.

The MIXACO laboratory container mixer Lab CM is suitable for mixing small quantities. In addition to product development, these are also required for production monitoring. Despite its compact size, it has all the advantages of a large container mixer. Especially when used in laboratories, the container with volumes of 6 or 12 liters is very easy to transport.

The MIXACO laboratory mixer Lab CM works just like a large container mixer Vortex . However, in the case of the laboratory container mixer, the mixing container is only up to 12 liters in size and can be replaced quite easily by hand.

Our laboratory mixer in the container mixer version is a powerful and versatile mixer for shortening the path from product development to production readiness or for testing new formulations.

The container is fixed to the mixing head and turned upside down by 180° for the mixing process. The mixing material is transported upwards by the mixing tools in the container and sinks back down again by gravity. The result is perfect mixing without dead spaces.

The control of the laboratory container mixer is based on a Siemens S7 PLC and meets today’s requirements for safety, efficiency and economy. The development and programming of the control system from a single source ensures optimum integration of the mixer components. Alternatively, it is also possible to use Allen-Bradley components (incl. Panelview operating unit).

The control can also be designed in accordance with UL/NEMA standards. In addition, the control can be equipped with an interface for data exchange with a higher-level control system.

The control can also be designed according to UL / NEMA. In addition, the control system can be equipped with a touch panel TP700 to create up to 99 mixing programs in tabular form, each with ten working steps. Data acquisition and storage of the measured values takes place. Comprehensive data acquisition on temperature, speed, active power, torque, moisture content and numerous other parameters is possible, which are visualized via the touch panel. be equipped for data exchange to a higher-level control system.

Control in accordance with UL/NEMA standards using an Allen-Bradley PLC and PanelView control panel is also possible.

Our laboratory mixer is ideal for product development, trial mixing, quality assurance and small-scale production. Mix components with very different bulk densities, structures and sizes together. Even dusts and finest particles are optimally mixed. Break down agglomerates into primary particles. Liquids and gases can be added during mixing.

For mixing processes with heat supply, the stationary laboratory mixer can be designed as a heating mixer “ LAB HM “. The mixture is precisely tempered via a double-walled design of the mixing vessel.

Realize a wide variety of coating processes, such as coating with liquid raw materials, which are subsequently re-solidified by controlled cooling on the particles.

The MIXACO laboratory mixer Lab CM is suitable for mixing small quantities. These are needed for research and product development, quality assurance and for small-scale production in all industries.

The different mixing tools of the laboratory container mixer make it a very versatile mixer that can be used in all industries.

Compared to small benchtop units, it offers the complete functionality of a large production mixer. The upscaling from laboratory to production is easy and reliable.

The MIXACO laboratory container mixer Lab CM can be expanded in many ways. Additional adaptations can be developed in cooperation with our engineers according to your individual requirements. We will be happy to advise you on the possibilities:

Test our mixers at our test center—using your own raw materials, of course.

Have your mixing process reviewed by our mixing professionals—free of charge and with no obligation.

At our test centers, we can optimize all parameters for your compound.
