Aggregate Gate

The Vortex® Aggregate Gate™ is designed to handle demanding applications involving materials such as sand, gravel, whole grains, and coal.

• Seals are protected by a series of deflectors and retainers to reduce wear and extend service life
• Removable bonnet cover for easy inspection of the valve body
• The displacement pocket prevents wedging and packing into an end seal
• An optional return chute redirects material that has migrated into the hood area back into the material flow
• Made from specialized metals and polymers for application-specific durability and abrasion resistance
• Modifications allow the gate to be used in higher-temperature applications up to 550°F | 290°C
• Optional side-mounted handwheel with rack-and-pinion gearing for quick, manual operation
• Blade made of abrasion-resistant steel
• Replaceable, abrasion-resistant liners for durability and a longer service life

Seals are protected by a series of deflectors and retainers to reduce wear and extend service life

Removable bonnet cover for easy inspection of the valve body

A displacement pocket prevents wedging and packing into an end seal

An optional return chute redirects material that has migrated into the hood area back into the material flow

Made from specialized metals and polymers to provide application-specific durability and abrasion resistance

Modifications allow the gate to be used in applications with higher temperatures, up to 550°F | 290°C

Optional side-mounted handwheel with rack-and-pinion gearing for quick, manual operation

Blade made of abrasion-resistant steel

Replaceable, abrasion-resistant liners for durability and a longer service life

Heavy-duty and/or abrasive dry bulk solid materials with large particle sizes, such as minerals, coal, and aggregates

Available in square or rectangular sizes. Round transition options are available

Standard flange; custom flanges are available

180°F | 80°C for a standard gate, with modifications that allow temperatures up to 550°F | 290°C

Carbon steel, 304 stainless steel, 235 BHN abrasion-resistant steel, SAE 660 bronze

Belted rubber, chute rubber, bronze

Hardened steel, 304 stainless steel & bronze, 25% glass-filled PTFE, nylon, bronze

Double-acting air cylinder, handwheel, chain wheel, electric actuator, hydraulic actuation

Magnetic reed switches, proximity switches, or mechanical limit switches

ATEX Zone 20 (internal), ATEX Zone 21 (external), FDA

The blade and frame are made of 304 stainless steel. The rollers are made of 440 stainless steel, and the roller stud bolts are made of 304 or 18-8 stainless steel.

Modifications have been made to allow for continuous operation at 250°F (121°C) and intermittent operation at 300°F (149°C).

Modifications have been made to allow for continuous operation at 400°F (204°C) and intermittent operation at 450°F (232°C).

The slide blade is made of AR plate for handling more abrasive materials.

The dust seal will help eliminate or reduce dust emissions into the atmosphere. An example of an application where the Enhanced Bonnet Seal option would be useful is handling rocks in dusty conditions. *Additional modifications are available depending on the application.
