Titan Pressure Valve

The Vortex® Titan Pressure Valve™ is designed for higher-pressure applications up to 100 psig (6.8 barg) and higher temperatures up to 660°F (350°C).

• Replaceable packing gland for in-line maintenance
• Spring-loaded blade guides for secure gate closure
• Air gap between the valve body and the actuator to reduce heat transfer into the cylinder
• The beveled blade prevents material from packing into the end seat
• Effective sealing of materials and dust against the closed blade and the atmosphere
• Blade and seats made of 440 C stainless steel (Rockwell hardness 60 C)
• Ductile iron housing for operator safety in high-temperature applications
• For temperature resistance, constructed without elastomers or polymers
• Narrow profile for applications with limited space

Replaceable packing gland for in-line maintenance

Spring-loaded blade guides for secure gate closure

Air gap between the valve body and the actuator to reduce heat transfer into the cylinder

The beveled blade prevents material from packing into the end seat

Positive seal against materials and dust across the closed blade and to the atmosphere

Blade and seats made of 440C stainless steel (Rockwell hardness 60C)

Ductile iron housing for operator safety in high-temperature applications

For temperature resistance, constructed without elastomers or polymers

Narrow profile for applications with limited space

Gravity flow, dilute-phase, and dense-phase pneumatic conveying applications. Can handle differential pressures up to 100 psig | 6.8 barg | 0.69 MPa, depending on gate size. Can be used in pressure or vacuum systems.

Heavy-duty and/or abrasive dry bulk solid materials

440C stainless steel (Rockwell Hardness 60 C) & ductile iron

440C stainless steel (Rockwell hardness 60 C)

Magnetic reed switches, proximity switches, or mechanical limit switches

ATEX Zone 20 (internal), ATEX Zone 21 (external)
